| Model |
|
HS-4IN1-H009AA
|
|
Pick up device
|
|
1/2.8” SONY CMOS : 2.0 Mega
|
|
Solution
|
|
2441H + SONY 323
|
|
Resolution
|
|
1920(H) x 1080(V)
|
|
Video Output
|
|
AHD / CVBS (optional : TVI / CVI)
|
|
Synchronization
|
|
Internal
|
|
Scanning System
|
|
2:1 Interlace
|
|
Electronic Shutter
|
|
Auto 1/60 (1/50) ~ 1/50,000 sec.
|
|
Min. Illumination
|
|
0.01 Lux
|
|
Video Output
|
|
1.0 Vp-p / 75 ohm composite
|
|
IR Distance
|
|
40M
|
|
Coaxial Cable Transmition Distance (3C/5C)
|
|
300 / 500 M
|
|
Twisted Cable Transmition Distance(Cat 5.e standard)
|
|
200 M
|
|
Lens Type
|
|
Board Lens: 3.6/6mm ; Vari-focal Lens 2.8~12mm (optional)
|
|
Control
|
|
CoC (Control Over Coaxial)
|
|
Power Source
|
|
DC12V±10% / 1A
|
|
Operating Temperature
|
|
-10℃ ~ 50℃ (14℉ ~ 122 ℉)
|
|
Storage Temperature
|
|
-20℃ ~ 70℃ (-4℉ ~ 158℉)
|
|
Dimension
|
|
142(W) x 136(H) x 323(D) mm
|
|
Weatherproof
|
|
IP66
|
