| Camera |
| mage Sensor |
1 / 2.8" Progressive Scan CMOS |
| Effective Pixels |
1920 × 1080 |
| Lens |
30× Zoom, f = 4.5 ~ 135 mm, F1.6 ~ F4.4 |
| Field of View |
H |
V |
D |
| 62 ° ~2.3° |
35° ~1.3° |
71° ~2.6° |
| Shutter |
60Hz: 1 / 1 s ~ 1 / 30,000 s |
| Min. Illumination |
Color:0.006 lux @F1.6(AGC ON)
B/W:0.003lux @F1.6(AGC ON)
0 lux ( IR ON ) |
| S / N Ratio |
Max 50dB |
| WDR |
True WDR, 2 frames in one, 120dB |
| White Balance |
Auto / Manual/ Indoor/Outdoor |
mage
Enhancement |
Day / Light |
HLC |
BLC |
Digital DNR |
Defog |
| IR Cut Filter |
YES |
YES |
3 DNR |
YES |
| Privacy Masks |
4 programmable
privacy masks |
Gain |
Auto / Manual |
| Focus Mode |
Auto / Manual |
Working
Distance |
Wide:1.0m~INF
Tele: 1.5m~INF |
| R Distance |
150 m |
Smart IR |
Support |
| PTZ |
| Pan Range |
360° endless rotation |
| Pan Speed |
0.5° /s ~ 80 ° /s |
Preset speed : 150° /s |
| Tilt Range |
0° ~ 93° ( auto-flip ) |
| Tilt Speed |
0.5 ° /s~ 70 ° /s |
Preset speed : 120 ° /s |
| Proportional Zoom |
Support |
| Zoom Speed |
Approx. 4s (optical lens, Wide-TELE) |
| PTZ Control |
Yes |
Preset |
360 |
| 3D Positioning |
Support |
PTZ Position Display |
Support |
| Auto Flip |
Yes |
Power-off Memory |
Support |
| Cruise |
8 cruises, up to 16 presets for each cruises |
| Track |
4 tracks, record time over 3 minutes for each track |
| Action Mode |
Preset/Cruise/Track/Auto Scan/Random Scan |
| Scheduled Task |
Preset/Cruise/Track/Random Scan/Boundary Scanning/
Dome Reboot |
| Image |
| Video Compression |
H.265 / H.264 / MJPEG |
H.265 Compression
Standard |
Main Pofile |
SVC |
Support |
| Resolution |
1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1(704 × 576),
CIF, 480 × 240 |
| Main Stream (S1) |
1080P / 720P @30 fps |
| Sub Stream (S2) |
720P / D1 / CIF @30 fps |
| Third Stream (S3) |
D1 / 480 × 240 / CIF @30 fps |
| Bit Rate |
128 Kbps ~ 6 Mbps |
| Storage |
| SD card |
Built-in micro SD card slot; up to 128 GB |
| Audio |
| Audio Compression |
G.711 A / U |
Two-way audio |
YES |
| Interfaces |
| Network |
1 x RJ45 10M/100M Ethernet, PoE(802.3at) |
| Audio line in |
1CH |
Alarm Input |
1CH |
| Audio line out |
1CH |
Alarm Output |
1CH |
