| Model |
|
HS-HDC10Z1
|
|
Pick up device
|
|
1/2.7” Sony 2.0 Megapixel Progressive Exmor TM CMOS Sensor
|
|
Resolution
|
|
1920x1080P@60fps, 1920x1080P@30fps,
1280x720P@60fps, 1920x1080P@50fps,
1920x1080P@25fps,
1280x720P@50fps
|
|
Video Output
|
|
HD-SDI
|
|
Lens type
|
|
10X optical lens
|
|
Electronic Shutter
|
|
AUTO (1/50(60)~1/10,000 sec.)
|
|
Min. Illumination
|
|
0 lux / F1.4 (IR ON)
|
|
Digital Video Output
|
|
Gold-plated BNC connector x1 (SDI)
|
|
DWDR
|
|
ON/OFF
|
|
Defog
|
|
ON/OFF
|
|
AGC
|
|
0~150
|
|
White Balance
|
|
AUTO (2500°~8000°K) / MANUAL/INDOOR/OUTDOOR/FULL OPEN
|
|
IR cut
|
|
Auto/ Day/ Night
|
|
2DNR
|
|
ON / OFF
|
|
OSD Control
|
|
Button
|
|
OSD Language
|
|
ENGLISH
|
|
Power Source
|
|
DC12V ± 10% / 1A
|
|
Power Consumption
|
|
DC12V : 4.8W
|
|
Current
|
|
DC12V : 400mA(Max)
|
|
Operating Temperature
|
|
-10°C ~50°C (14°F ~122°F)
|
|
Storage Temperature
|
|
-20°C ~70°C (-4°F ~158°F)
|
|
Dimension
|
|
88.5(W) x187(H) x 199.2(D)mm
|
